- Graphics Engine AXRX 6500 XT 4GBD6-DH/OC
Video Memory 4GB GDDR6
Stream Processor 1024 Units
Engine Clock(OC) TBD
Engine Clock(STD/Silent)
Memory Clock 18.0 Gbps
Memory Interface 64-bit
DirectX® Support 12
Bus Standard PCIE 4.0
Standard Display Connectors 1 x HDMI 2.1 , 1 x DisplayPort 1.4
Customized Specifications
Product Remark 'Game Clock' is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
'Boost Clock' is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to:thermal conditions and variation in applications and workloads.
Feature Support
OpenGL Support
CrossFireX? Technology support (DirectX® 12/Vulkan?)
AMD Stream Technology Support
AMD Eyefinity Technology Support
AMD Hypermemory
Maximum Resolution
VGA
DVI
DisplayPort 7680×4320
HDMI 7680×4320
Power Specs + Board Dimensions
Board Dimensions 191mmx126mmx40mm
Minimum System Power requirement (W) 400W
Extension Power Connector One 6-Pin PCI Express Power connector
