P/N
CA-1S4-00S1WN-00
TIPO DE CAJA
Micro Case
DIMENSIONES (AL X AN X PR)
426 x 210 x 408.5 mm
(16.8 x 8.3 x 16.1 inch)
PESO NETO
5.26 kg / 11.6 lbs.
PANEL LATERAL
3mm Tempered Glass x 1
COLOR
Black
MATERIAL
SPCC
SISTEMA DE REFRIGERACIÓN
Front(intake):
120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 2
BAHÍAS DE EXPANSIÓN
2 x 3.5?, 2 x 2.5? or 3 x 2.5?
RANURAS DE EXPANSIÓN
4
PLACAS BASE
6.7? x 6.7? (Mini ITX), 9.6? x 9.6? (Micro ATX)
PUERTOS E/S
USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1
FUENTE DE ALIMENTACIÓN
Standard PS2 PSU (optional)
COMPATIBILIDAD VENTILADORES
Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Rear:
1 x 120mm
COMPATIBILIDAD RADIADORES
Front:
1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 240mm, 1 x 120mm
1 x 140mm
Rear:
1 x 120mm
LIMITACIONES
CPU cooler height limitation:
160mm
VGA length limitation:
300mm(With radiator)
350mm(Without radiator)
PSU length limitation:
200mm (With HDD Cage)
