- Form Factor (Midi, Micro, Mini ITX, Full) TOWER
Chassis SPCC :0.6mm
PSU Form Factor Bottom/ATX
M/B Form Factor E-ATX/ATX/M-ATX/ITX
Front Panel ABS,Mesh
Top Panel Metal cover
Side Panel
Left Tempered Glass
Right metal cover
External Drive Bay(s)
5.25" (ODD) x0
3.5" x0
Internal Drive Bay(s)
3.5" (HDD) x2
2.5" (SSD) x3
1x3.5HDD+3x2.5SSD or 2x3.5HDD+2x2.5SSD
I/O
Buttons x3
USB2.0 Port(s) x2
USB3.0 Port(s) x1
USB3.1 Port(s) x0
Audio Support x1 (COMBO AUDIO)
RGB Controller x1 (built-in Master-Fan)
Controller max. fans x8
Cooling Fan
Front 3x120mm ARGB Fan (FN12A-M6+2xFN12A-S6)
Top 3x120mm ,2x140mm (Fan optional)
Rear 1x12cm ARGB Fan (FN12A-S6)
M/B Cover 2x120mm (Fan optional)
PSU Cover 2x120mm (Fan optional)
Water Cooling Support
Front 120mm, 140mm,240mm,280mm,360mm
Top 120mm, 140mm,240mm,280mm,360mm
Rear 120mm
M/B Cover 120mm, 240mm
Dust Cover Bottom, right side panel and top cover with dust filter
Slots x7
VGA Card Length up to 410mm(front cover w/o fan)
CPU Cooler Height 165mm
SPS Length up to 265mm(front cover w/o Water Cooling)
Cable Management Depth 25mm
